5KW Super Silent Diesel Generator

With 1-cylinder, 4-strock, air-cooled diesel engine, the 5KW Super Silent Diesel Generator is economical and practical, and safe to use. The body is light, simple to operate. Low noise creates a comfortable power supply environment for you. Muffler and AVR are provided. It can save the tedious maintenance, and you can handle it at any time....

Send Inquiry Chat Now

With 1-cylinder, 4-strock, air-cooled diesel engine, the 5KW Super Silent Diesel Generator is economical and practical, and safe to use. The body is light, simple to operate. Low noise creates a comfortable power supply environment for you. Muffler and AVR are provided. It can save the tedious maintenance, and you can handle it at any time.

When we use diesel generating sets in daily life, we must pay attention to the instructions, so as to extend the service life of diesel generating sets. Special attention should be paid to the generator air filter, which is a humble but important part of the entire generator set. After a long period of operation, especially in the environment and regions where the air quality is relatively poor, once the air filter is dirty, it may cause serious mechanical accidents. When it is found that the generating set is not operating normally, do not force to operate it. Once started, the wear will be intensified, and even scrapped. When stopping the machine, check the air filter on the generator in time and check if there is any blockage, so as to avoid the service life of the generator.

Our exporting area includes Europe, Middle East, Southeast Asia, South America, Oceania, Africa, countries including Germany, Poland, Turkey, Australia, Parkistan, Phillppines, Indonesia, Brazil, Argentina, Russia, France, Uzbekistan, Egypt, Nigeria, etc. The way to start, single phase or three phase, colors are optional. Our supply ability is 10000 sets per month.

In case of any questions, please contact us if you want to know more.

Quick Details

Name:5KW Super Silent Diesel Generator

Model Number: BS6500DSERated Current: 12V/8.3A

Output Type: AC Single Phase

Speed: 3000/3600

Frequency: 50/60Hz

Rated Power: 5.0/5.5KW

Rated Voltage: 110/220/230/380


Generator Output Power: 2kw, 3kw, 4.2kw, 5kw, 6kw, 7kw, 8kw, 9kw, 10kw, 12kw

Video Show


Feature



Advantage

20180705_113752_033.jpgDescription


Parameter

Engine

Engine Model

BS186F(E)

Engine Output

6.3kw

Bore x stroke

86 x 70mm

Displacement

456cc

Compression ratio

19:1

Engine Type

Air Cooled; Single Cylinder

Ignition system

Compression combustion

Generator

Rated frequency

50 / 60hz

Rated voltage

220 / 380v

Rated output power

5.0kw

Max output power

5.5kw

Alternator

Copper

Power factor

1 cosθ

Phase

Single phase / Three Phase

Socket

2 x 220v

Structure type

Silent type

Starting system

Key start

Fuel tank capacity

16L

Noise level

78db

Net/Gross weight

163 / 165kg

Overall dimension

960*570*760mm


Hot Tags: 5kw super silent diesel generator, China, suppliers, factory, made in China
