powered diesel generator with recoil & e-start
| no brand | 30 sets |
| OEM standard | 50 sets |
| OEM special | 100 sets |
BS12000DSE Specifications
| model | BS12000DSE |
|---|---|
| maximum power (KW) | 12.0 |
| rated power (KW) | 11.0 |
| rated output voltage (Volt) | 1 phase / 3 phase (optional) |
| over load protector | yes |
| rated frequency (Hz) | 50 / 60 Hz |
| rated current (Amp) | 16 |
| power factor | 1.0 (single phase) / 0.8 (three phase) |
| fuel tank capacity | 32L |
| fuel option | 0# (summer)、-10#（winter) diesel |
| socket rating | 16A |
| self start motor | electric start |
| fuel consumption at 100% Load | 4L/h |
| fuel consumption at 75% Load | 3L/h |
| fuel consumption at 50% Load | 2L/h |
| continuous duration of operation at rated load (hour) | 8.0 |
| engine & emission specifications | |
|---|---|
| engine model | BS292FE |
| fuel type | Diesel |
| engine speed | 3000(50hz)/3600(60Hz) |
| bore * stroke | 2-92*75 |
| engine displacement | 997 |
| engine/motor type | E-line、4-Stroke、Air-cooled、Diesel Engine |
| engine oil grade | 10W/30SAE |
| fuel capacity | / |
| oil capacity | 2.5L |
| recoil start | No |
| electric start | Yes |
| alternator | |
|---|---|
| type of alternator | 100% copper (corrective wave) |
| rotor RPM | 3000(50Hz)/3600(60Hz) |
| alternator size | 245*150 |
products description
BISON powered diesel generator with recoil & e-start is a reliable generator that is perfect for various applications. It is powered by a durable diesel engine and features both recoil and electric start for easy operation. The recoil and electric start feature are one of the most key features of this generator. It makes it easy to start the generator, even in cold weather or when the battery is low. This is especially important for diesel generators, which can be difficult to start manually. In addition to the recoil and electric start feature, the BISON powered diesel generator also offers several other features that make it a great choice for diesel generator dealers, including:
- Powerful diesel engine that delivers reliable power. With a maximum power output of 12 KW and a rated power of 11 KW, this generator provides ample power to meet a variety of power needs.
- Durable construction that can withstand heavy use. Uses 100% Copper (Corrective Wave) alternator, heavy-duty frame, shock-absorbing mounts, and weatherproof housing to withstand challenging environments.
- Easy-to-use controls and operation. With a gross weight of 280 kg, ensuring ease of transport and installation. Electric start and recoil start-up options provide convenience for your customers. The visual control panel ensures easy operation.
- Low noise levels. Operating at a noise level of 70 dB, this generator strikes a balance between power and noise, making it suitable for various applications.
- Fuel-efficient operation. The fuel consumption rates are 4L/h (100% load), 3L /h (75% load) and 2L/h (50% load). The fuel tank capacity is 32L, which can run continuously for 8 hours at rated load, minimizing downtime and refueling frequency.
- A variety of safety features. Built-in protection features prioritize customer safety and equipment longevity. Includes overload protector, low oil shutdown, circuit breaker protection, etc.
- Customized options. Provide your customers with single-phase and three-phase options to make this power generation. The machine is suitable for various electrical settings.
A class core parts
100% all-copper motor
Offering durability and superior energy efficiency
Fuel injection pump
Higher injection pressure, optimal injection rate, higher precision injection timing control and quantity control.
Powerful pull plate
Easy to start pull plate, guarantee more than 10,000 pulls
robust frames
Professional welding and painting process to ensure the beauty and stability of the rack
tight quality contorl
powered diesel generator with recoil & e-start Perfect inspection process
Inspection process leaves no room for compromise, ensuring that every diesel generator we produce is flawless.
- Water Test: Ensures 100% cylinder tightness, detecting any possible leaks.
- Unit Comprehensive Intelligent Test Cabinet: Each generator undergoes a full inspection to confirm reliability and accuracy.
- Withstand Voltage Tester Inspection: Every generator is fully inspected, ensuring precise electrical safety measurements.
- Strengthened Laboratory Standards: Our lab exceeds national sampling standards, resulting in superior product durability.
powered diesel generator with recoil & e-start assembly process
- Use special equipment to assemble, ensure the beaning, oil seal, governor gear effectively fit
- When assembling nuts for each muffler, spring pads need to be installed to ensure the fit of each component and the maximum noise reduction effect
- Use a special air gun, and use different torque standards for different parts
Water test is required in each engine assembly to ensure the tightness of itself - Pay attention to small details, add thread glue and spring washers to the bolts; add support feet to the motor bracket
- More than 20 debugging processes throughout the whole process to ensure that the machine 100% meets the factory requirements
Professional technicians with 15-20 years of experience
Performance Commissioning
diesel generator assembly
Artwork QA
Full Inspection
Generator Specialized Inspection
Parts assembly
Core Assembly
Power Specialized Inspection
support
- Competitive prices and high quality
- 1-year warranty and 24-hour after-sales support
- Multi-language marketing materials and comprehensive technical documentation
- Video follow-up of order placement, production, and delivery processes
- OEM/ODM or use BISON brand
Discounted Accessories
24-hour online, 5-minute response
Engineer on-site service
Packaging & Delivery
Packaging details: brown strong carton, generator is protected with poly bag, wooden, 1pc / carton. Lead Time: Shipped in 25 days after payment.
