5kw super silent diesel generator three phase
- Reliable operation that it operates smoothly with minimal vibration.
- With the scientific and ergonomic design, it has fast speed and high output, greatly increasing the working efficiency.
- Equipped with the big fuel tank as well as the premium heat dissipation, the machine is able to keep working up to 8 hour.
- Strong construction, it is resistant to corrosion, dust and oxygen with the good treatment.
| no brand | 30 sets |
| OEM standard | 50 sets |
| OEM special | 100 sets |
BS6800DSE Specifications
| model | BS6800DSE |
|---|---|
| maximum power (KW) | 5 |
| rated power (KW) | 4.6 |
| rated output voltage (Volt) | 1 phase / 3 phase (optional) |
| over load protector | yes |
| rated frequency (Hz) | 50 / 60 Hz |
| rated current (Amp) | 16 |
| power factor | 1.0 (single phase) / 0.8 (three phase) |
| fuel tank capacity | 14.5L |
| fuel option | 0# (summer)、-10#（winter) diesel |
| socket rating | 16A |
| self start motor | electric start |
| fuel consumption at 100% Load | 1.9L/h |
| fuel consumption at 75% Load | 1.45L/h |
| fuel consumption at 50% Load | 0.95L/h |
| continuous duration of operation at rated load (hour) | 7.5 |
| engine & emission specifications | |
|---|---|
| engine model | BS186FAE |
| fuel type | Diesel |
| engine speed | 3000(50hz)/3600(60Hz) |
| bore * stroke | 86*72 |
| engine displacement | 418 |
| engine/motor type | single-cylinder、vertical、4-stroke、air-cooled、diesel engine |
| engine oil grade | 10W/30SAE |
| fuel capacity | 5.5L |
| oil capacity | 1.65L |
| recoil start | No |
| electric start | Yes |
| alternator | |
|---|---|
| type of alternator | 100% copper (corrective wave) |
| rotor RPM | 3000(50Hz)/3600(60Hz) |
| alternator size | 190*130 |
products description
The 5KW super silent diesel generator three phase is a power machine that uses diesel as a fuel and a diesel engine as a prime mover to drive generators to generate electricity, which is specialized in its silent operation with no noise.
Many people like it as a backup or temporary power source for home use because it has a small size that makes it take up little space. The bottom wheels make it easy to move which is a portable one, convenient to move and carry.
AVR, which can automatically regulate voltage, is on this machine. It is safe to operate that the oil alert system is able to shut down engine automatically when low oil is detected. Circuit breakers can stop engine automatically when overloaded.
Manufactured with superior quaity, the 5KW super silent diesel generator three phase is deigned with the powerful generator which is able to make sure the stable operation with high output, which can grealty enhance the working efficiency.
In the selection of diesel generating sets, here are some main factors to be considered:
The purpose of the unit. Since they can be used in common use, backup and emergency three conditions. Therefore, different uses have different requirements for them.
- Load capacity. The load capacity and the variation range of the load should be selected according to different uses.
- Environmental conditions (mainly altitude and climatic conditions) for use of the unit.
- Selection of generator and excitation mode.
- Selection of automation features.
Different types of generators are optional, which can meet various demands. Other options include recoil start, or electric start, single phase, or three phase, colors. Please tell us your needs and we will try our best to satisfy you.
A class core parts
100% all-copper motor
Offering durability and superior energy efficiency
Fuel injection pump
Higher injection pressure, optimal injection rate, higher precision injection timing control and quantity control.
Powerful pull plate
Easy to start pull plate, guarantee more than 10,000 pulls
robust frames
Professional welding and painting process to ensure the beauty and stability of the rack
tight quality contorl
5kw super silent diesel generator three phase Perfect inspection process
Inspection process leaves no room for compromise, ensuring that every diesel generator we produce is flawless.
- Water Test: Ensures 100% cylinder tightness, detecting any possible leaks.
- Unit Comprehensive Intelligent Test Cabinet: Each generator undergoes a full inspection to confirm reliability and accuracy.
- Withstand Voltage Tester Inspection: Every generator is fully inspected, ensuring precise electrical safety measurements.
- Strengthened Laboratory Standards: Our lab exceeds national sampling standards, resulting in superior product durability.
5kw super silent diesel generator three phase inspection process
- Use special equipment to assemble, ensure the beaning, oil seal, governor gear effectively fit
- When assembling nuts for each muffler, spring pads need to be installed to ensure the fit of each component and the maximum noise reduction effect
- Use a special air gun, and use different torque standards for different parts
Water test is required in each engine assembly to ensure the tightness of itself - Pay attention to small details, add thread glue and spring washers to the bolts; add support feet to the motor bracket
- More than 20 debugging processes throughout the whole process to ensure that the machine 100% meets the factory requirements
Professional technicians with 15-20 years of experience
Performance Commissioning
diesel generator assembly
Artwork QA
Full Inspection
Generator Specialized Inspection
Parts assembly
Core Assembly
Power Specialized Inspection
Warranty Information
Discounted Accessories
24-hour online, 5-minute response
Engineer on-site service
Packaging & Delivery
Packaging details: brown strong carton, generator is protected with poly bag, wooden, 1pc / carton. Lead Time: Shipped in 25 days after payment.
