3kw dual fuel generator with fuel shut off & co watchdog
| no brand | 30 sets |
| OEM standard | 50 sets |
| OEM special | 100 sets |
BS3500i Specifications
| model | 3500i-1C |
|---|---|
| Maximum power of generator (KW) | 3.2 |
| Rated power of generator (KW) | 3 |
| Voltage (Volt) | 120/230/240V |
| Rated frequency (Hz) | 50/60Hz |
| 12V DC output | 8.3A/12V |
| Start type | Recoil Start |
| Fuel tank capacity | 7.5L |
| Running time @100% load | 3.5h |
| Fuel consumption at 100% Load | 2.15L/h |
| Waveform distortion rate | <5 |
| Noise level (dB) at 50% load (from 7-meter distance) | 72 |
| Compliance | EPAⅢ/EU V/CE |
| engine & emission specifications | |
|---|---|
| Engine model | H210 |
| Engine type | Single Cylinder, 4 Strokes, Forced Air-cooling, Overhead Valves |
| Fuel type | Gasoline |
| Bore * stroke | 70*55mm |
| Engine displacement | 212cc |
| Net power | 4.3kw(3600r/min) |
| Max. torque | 12N.m(2500r/min) |
| Ignition system | T.C.I |
| Starting system | Automatic/Remote/h |
| Oil capacity | 0.6L |
| Fuel tank capacity | 3.6L |
products description
As a trusted leader in China’s generator industry, BISON has launched the 3kw dual fuel generator with fuel shut off and CO watchdog, a perfect blend of power, efficiency and safety features designed to meet the industry standards. This versatile generator is perfect for generator dealers.
Why choose 3kw dual fuel generator?
- Dual fuel generator: The dual fuel function switches between gasoline and propane to extend the running time. With a 7.5L tank capacity, it can run for 3.5 hours at 100% load, ensuring continuous reliable power.
- 3kw generator: With a peak power of 3.2kw and a rated power of 3kw, it can provide continuous energy output to meet market needs. The single-cylinder 4-stroke engine is equipped with overhead valves and forced air cooling to extend service life and improve operating efficiency.
- Certificate guarantee: Each 3kw dual fuel generator fully complies with EPA III, EU V and CE regulations, meeting global safety and emission requirements. This compliance not only ensures user safety, but also opens up a wider market for dealers.
- Generator with fuel shut off: Automatically cuts off the fuel supply in the event of a potential hazard. The generator with fuel shut off significantly reduces the risk of fuel leaks and accidental fires, protecting the equipment and its surroundings. At the same time, fuel will not be in the carburetor, which helps to extend the life of the generator.
- Generator with CO watchdog: Carbon monoxide (CO) poisoning is dangerous in enclosed spaces. The 3kw dual fuel generator is equipped with an integrated CO monitor that continuously monitors the air quality around the equipment. If CO rises to unsafe values, the generator automatically shuts down to ensure safe use.
A class core parts
Dive deep into the world of BISON high-quality inverter generators, where unrivaled performance meets highest reliability.
100% all-copper motor
Offering durability and superior energy efficiency
Domestic top carburetor
high atomization level, ensuring optimal fuel efficiency and smooth engine operation.
Powerful pull plate
Easy to start pull plate, guarantee more than 10,000 pulls
robust frames
Professional welding and painting process to ensure the beauty and stability of the rack
tight quality contorl
3kw dual fuel generator with fuel shut off & co watchdog Perfect inspection process
Inspection process leaves no room for compromise, ensuring that every inverter generator we produce is flawless.
- Water test: Ensures 100% cylinder tightness, detecting any possible leaks.
- Unit comprehensive intelligent test cabinet: Each generator undergoes a full inspection to confirm reliability and accuracy.
- Withstand voltage tester inspection: Every generator is fully inspected, ensuring precise electrical safety measurements.
- Strengthened laboratory standards: Our lab exceeds national sampling standards, resulting in superior product durability.
3kw dual fuel generator with fuel shut off & co watchdog assembly process
- Use special equipment to assemble, ensure the beaning, oil seal, governor gear effectively fit
- When assembling nuts for each muffler, spring pads need to be installed to ensure the fit of each component and the maximum noise reduction effect
- Use a special air gun, and use different torque standards for different parts
- Water test is required in each engine assembly to ensure the tightness of itself
- Pay attention to small details, add thread glue and spring washers to the bolts; add support feet to the motor bracket
- More than 20 debugging processes throughout the whole process to ensure that the machine 100% meets the factory requirements
Professional technicians with 15-20 years of experience
engine & alternator assembly
invertor assembly
silent case assembly
power testing
coverplate assembly
artwork QA
packing
weight storage
Support
Become a BISON dealer and offer the 3kw dual fuel generator with fuel shut off and CO watchdog. Provide your customers with a product that combines top safety features, regulatory compliance, and excellent performance, and increase your brand influence with extensive positive customer reviews.
Discounted Accessories
24-hour online, 5-minute response
Engineer on-site service
Packaging & Delivery
Packaging details: brown strong carton, generator is protected with poly bag, wooden, 1pc / carton. Lead Time: Shipped in 25 days after payment.
Speak with a BISON sales manager
Contact us today for expert advice.
