petrol powered centrifugal water pump

4-Stroke|210cc|50mm
ce 1
tuv
nps
2 years warranty
epa 1
no brand30 sets
OEM standard50 sets
OEM special100 sets

WP20HI Specifications

modelWP20HI(175mm)
Outlet Size(mm)50
Inlet Size(mm)50
Displacement Q. max(m3/h)30
Lift H. max(m)75
Suction (m)7
Fuel Tank Capacity3.6L
Fuel option#92, #95 Unleaded Gasoline
Self start motorRecoil start
Fuel consumption radio≤395g/kW/hh
Ignition systemT.C.I
engine & emission specifications
Engine ModelBS170F
Fuel TypeGasoline
Engine Speed(RPM)3600
Bore × Stroke(mm)70*54
Engine Displacement(cc)210
Engine/Motor Type1-Cylinder, Air-Cooled, 4-Stroke, Direct Injected,OHV
Engine Oil grade#5W-40
Fuel Capacity/
Low Oil Shutdown/AlertYes
Recoil StartYes
Electric StartOptional

WP20HI is a reliable and efficient unit with a self-priming design for easy operation and a rugged construction to handle heavy-duty tasks. Known for its portability and rugged construction, it is suitable for use in remote or off-grid areas where there is no electricity. The pump generates centrifugal force by rotating the impeller to effectively move water through pipes for a variety of applications such as irrigation, construction, and drainage.

Outstanding qualities of a petrol-powered centrifugal water pump

  • BISON WP20HI petrol powered centrifugal water pump is equipped with a high-performance BS170F engine with a large displacement of 210cc.
  • The pump has excellent pumping capacity with a maximum displacement of 30 m³/h for efficient water transfer. It excels in challenging tasks with a maximum lifting height of 75 meters and a suction range of 7 meters, making it suitable for a variety of industrial and agricultural environments.
  • It has a recoil start function and can be equipped with an optional electric start function for easy ignition in any condition.
  • Protection features such as low oil level shutdown extend its service life.
  • Its rugged design ensures consistent performance in harsh working conditions.

A class core parts

engine connecting rod

engine connecting rod

The mechanical strength belongs to the density of ADC12 aluminum alloy cast aluminum, and the weight monitoring can ensure the consistency of structural tensile strength and processing CPK

engine piston

pump engine piston

Adopt Z109 material to increase the wear resistance and reduce thermal deformation, to ensure the weight of the piston and the accuracy of machining

engine case

pump engine case

Using high-precision fixtures, machining center equipment to ensure precision, and high-density material strength, BISON's box can meet the durability test for 125 hours, and can meet emission standards

pump head

intake and exhaust valves

BISON only adopts high-quality pump heads with sufficient materials (reasonable and thick alloy ratio) and excellent processing technology (oxidation resistance, corrosion resistance, mold, flatness, and sealing)

tight quality contorl

pump suction simulation test

petrol powered centrifugal water pump testing

BISON water pump comprehensive test bench is equipped with a comprehensive test tank, which is higher than the national standard sampling inspection type and durable, ensuring the quality of the product in all aspects.

Test the pump suction online and simulate negative pressure detection. 100% full inspection to determine the extremely low failure of the product.

Regular outdoor field testing of water pumps to ensure the pumping efficiency of the product in practice.

Professional technicians with 15-20 years of experience

performance commissioning

Performance Commissioning

machine assembly

Machine Assembly

artwork qa

Artwork QA

full inspection

Full Inspection

power specialized inspection

water pump specialized inspection

parts assembly

Parts assembly

core assembly

Core Assembly

water pump specialized inspection

Power Specialized Inspection

Partner with BISON

BISON is synonymous with quality in the water pump market. Our reputation is built on years of experience, innovative design and rugged engineering. By adding the WP20HI to your offering, you can provide your customers with a reliable tool. Contact us today to learn more about pricing, bulk orders and exclusive dealer offers.

gasoline water pump parts

Discounted Accessories

24 hour online 5 minute response

24-hour online, 5-minute response

engineer on site service

Engineer on-site service

Packaging & Delivery

Packaging details: brown strong carton, water pump is protected with poly bag, wooden, 1pc / carton.
Lead Time: Shipped in 25 days after payment.
