Overview
| Quick Details | |
| Condition: New | Usage: Automobile, Agriculture, GardenPump, Boat, etc |
| Fuel: Gasoline | Stroke: 4 Stroke |
| Cylinder: Single Cylinder | Cold Style: Air-cooled |
| Start: Electric Start | Place of Origin: Zhejiang, China (Mainland) |
| Brand Name: BISON | Model Number: BS168f-1 |
| Dimension(L*W*H): 400*325*340mm | Weight: 16 kg |
| Certification: CE, ISO | Warranty: 1Year |
| After-sales Service Provided: Engineers available to service machinery overseas | |
| Item: chinese gasoline engines | |
| Exporting Area: Europe, Middle East; Southeast Asia, South America, Oceania, Africa | |
| Engine type: 1-Cylinder, 4-strock, Air-cooled Gasoline Engine | |
| Exporting countries: Brazil, Argentina, Russia, France, Uzbekistan, Egypt, Nigeria | |
| Engine Spare Parts: Carburetor, Camshaft, Spark Plug, Piston, Crankshaft, Crankcase | |
| Output Power: 5hp, 5.5hp, 6.5hp, 7.5hp, 9hp, 13hp, 15hp All Have | |
| Engine Model: 168f-1 | HP: 6.5hp |
| Delivery Time: 20-25 days | |
SupplyAbility
SupplyAbility: 10000 Set/Sets per Month chinese gasoline engines
Packaging & Delivery
Packaging Details: brown strong carton, generator is protected with ploy bag, wool, 1pc / carton, chinese gasoline engines
Port: Ningbo / Shanghai Port
Lead Time: Shipped in 25 days after payment
Product Parameter
| Taizhou Bison Machinery., Ltd Gasoline Engine gx200 | ||
| Engine | Engine Model | BS168F-1 |
| Type | Air Cooled, Single Cylinder, 4 Stroke | |
| Engine Output | 6.5HP | |
| Bore x stroke | 68 x 54mm | |
| Displacement | 196cc | |
| Compression ratio | 8.5: 1 | |
| Ignition system | T.C.I | |
| Starting system | Recoil start / Key start | |
| Rated rotation speed | 3000 / 3600rpm | |
| Oil capacity(L) | 0.6L | |
| Fuel tank volume | 3.6L | |
| Ner/Gross Weight | 15 / 16kg | |
| 20GP | 630set | |
| 40HQ | 1505set | |
– Product Show
 |
 |
 |
 |
The mechanical strength belongs to the density of ADC12 aluminum alloy cast aluminum, and the weight monitoring can ensure the consistency of structural tensile strength and processing CPK
Adopt Z109 material to increase the wear resistance and reduce thermal deformation, to ensure the weight of the piston and the accuracy of machining
Using high-precision fixtures, machining center equipment to ensure precision, and high-density material strength, BISON's box can meet the durability test for 125 hours, and can meet emission standards
The valve is made of 40Cr10SiMo material. The exhaust valve can withstand high combustion temperature. When the load is heavy or the combustion condition is abnormal, the temperature limit will not be affected if the temperature limit is lower than 700-780°C.
Dedicated to engine testing, and equipped with quality control for sampling testing. BISON verifies and confirms the performance and reliability of each batch of engines to avoid possible product failures
Guarantee the sealing performance of the crankcase body structure and installation. Through professional instrument testing, poor sealing defects of installation and materials can be found, so as to avoid oil leakage and oil leakage of the engine and ensure the actual power efficiency.
The load output stability of the power can be confirmed online, and the configuration can be locked after stabilization to ensure high product consistency
Have questions about product specifications and prices? Want more products details? Want the purchasing habits of different countries? Let us know
Please contact the Sales Manager for a quick 1-minute quote
