Overview
Quick Details
Condition: New
Usage: Generator, water pump
Fuel: Gasoline
Stroke: 4 Stroke
Cylinder: Single Cylinder
Cold Style: Air-cooled
Start: Electric/ manual start
Place of Origin: Zhejiang, China (Mainland)
Brand Name: BISON
Model Number: BS168F
Dimension(L*W*H): 390x330x350mm
Weight: 16
Certification: CE, ISO
Warranty: 1Year
After-sales Service Provided: Engineers available to service machinery overseas
Engine Type: Singer Cylinder, 4 strock, Air Cooled Gasoline Engine
Engine Spare Parts: Carburetor, Camshaft, Spark Plug, Piston, Crankshaft, Crankcase
Exporting Area: Europe, Middle East;Southeast Asia, South America, Oceania, Africa
Exporting Countries: Germany, Poland, Turkey, Australia, Parkistan, Phillppines, Indonesia
Engine Feature: Japan Structure Small OHV Gasoline Engine
Engine Adaptive: Generator, Water Pump, Compressor, Mini-tiller, High Pressure Washer
Engine Output Power: 2.6HP, 5.5HP, 6.5HP, 7HP, 9HP, 13HP, 15HP, 18HP All Have
Engine Model: BS168F
Optional: Recoil Start, Electric Start, Color
Item: ohv gasoline engine 5.5hp
SupplyAbility
SupplyAbility: 10000 Set/Sets per Month 5.5hp gasoline engine
Packaging & Delivery
Packaging Details: brown strong carton, generator is protected with ploy bag, wool, 1pc / carton, 5.5hp gasoline engine
Port: Ningbo/Shanghai Port
Lead Time: Shipped in 25 days after payment
BISON (CHINA) Ohv Gasoline Engine 6.5hp 168f-1 Gasoline Engine
Product Parameter
Product Parameter
| Taizhou Bison Machinery., Ltd | Gasoline Engine | |
| Engine | Engine Model | BS168F-1 |
| Type | Air Cooled, Single Cylinder, 4 Stroke | |
| Engine Output | 6.5HP | |
| Bore x stroke | 68 x 54mm | |
| Displacement | 163cc | |
| Compression ratio | 8.5:1 | |
| Ignition system | T.C.I | |
| Starting system | Recoil start / Key start | |
| Rated rotation speed | 3000 / 3600rpm | |
| Oil capacity(L) | 0.6L | |
| Fuel tank volume | 3.6L | |
| Ner/Gross Weight | 15/16kg | |
| 20GP | 630set | |
| 40HQ | 1505set | |
BISON Certificate
Service
Bison is not only a manufacturer of engine/water pump/generators and pressure washer.We work to offer you a comprehensive service that covers all the needs that may meet, from the search for the electric generator that best suits your needs, through commercial support and constant and transparent communication throughout the sales process, up to the resolution of any problem or incident, assistance in the installation of the machine, repair or simply its maintenance.A complete portfolio of after-sales services and the best technical team at your service so that everything goes well, before, during and after the start-up of the products.
Contracts: the key to a successful partnership,all the order we receive we will sign a contact,the warranty term will be showed on the contract.Any electronic product requires timely service to function properly.Bison can meet any maintenance need, from preventative maintenance contracts to emergency breakdown response.
The mechanical strength belongs to the density of ADC12 aluminum alloy cast aluminum, and the weight monitoring can ensure the consistency of structural tensile strength and processing CPK
Adopt Z109 material to increase the wear resistance and reduce thermal deformation, to ensure the weight of the piston and the accuracy of machining
Using high-precision fixtures, machining center equipment to ensure precision, and high-density material strength, BISON's box can meet the durability test for 125 hours, and can meet emission standards
The valve is made of 40Cr10SiMo material. The exhaust valve can withstand high combustion temperature. When the load is heavy or the combustion condition is abnormal, the temperature limit will not be affected if the temperature limit is lower than 700-780°C.
Dedicated to engine testing, and equipped with quality control for sampling testing. BISON verifies and confirms the performance and reliability of each batch of engines to avoid possible product failures
Guarantee the sealing performance of the crankcase body structure and installation. Through professional instrument testing, poor sealing defects of installation and materials can be found, so as to avoid oil leakage and oil leakage of the engine and ensure the actual power efficiency.
The load output stability of the power can be confirmed online, and the configuration can be locked after stabilization to ensure high product consistency
