single-cylinder portable power generator
- 10″ tire wheels for all-terrain mobility
- Protected by low oil alert
- Electronic ignition and AVR included
- Runs 7 hrs @ 1/2 load
- Low oil level shut down,
- Voltage switch equipped for full power operation
| no brand | 30 sets |
| OEM standard | 50 sets |
| OEM special | 100 sets |
BS3000 Specifications
| Model | BS3000 |
|---|---|
| Maximum Power of the Generator (KW) | 3000 W |
| Rated Power of the Generator (KW) | 2600W |
| Rated output voltage (Volt) | 1 Phase / 3 Phases (Optional) |
| Over Load Protector (OLP) | YES |
| Rated frequency (Hz) | 50 / 60 Hz |
| Rated Current (Amp) | 16 |
| Power factor | 1.0 (Single Phase) / 0.8 (Three Phases) |
| Fuel Tank Capacity | 15L |
| Fuel option | #92, #95 Unleaded Gasoline |
| Socket rating | 16A |
| Self start motor | Recoil start/Electric start |
| Fuel consumption at 100% Load | 1.2kg/h |
| Fuel consumption at 75% Load | 1.1kg/h |
| Fuel consumption at 50% Load | 0.85kg/h |
| Continuous Duration of operation at Rated load (hour) | 8 |
| Ignition system | T.C.I |
| Noise Level (dB) at rated load (from 4-meter distance) | 93.2 |
| Engine & Emission Specifications | |
|---|---|
| Engine Model | BS170F |
| Fuel Type | Gasoline |
| Engine Speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| Bore × Stroke | 70*54mm |
| Engine Displacement | 210 cc |
| Engine/Motor Type | 1-Cylinder, Air-Cooled, 4-Stroke, Direct Injected，OHV |
| Engine Oil grade | #5W-40 |
| Fuel Capacity | 0.6L |
| Low Oil Shutdown/Alert | Yes |
| Recoil Start | Yes |
| Electric Start | Optional |
| Alternator | |
|---|---|
| Type of alternator | 100% Copper (Corrective Wave) |
| Rotor RPM | 3000 |
| Alternator Size | 160*110mm |
products description
Enjoy the power of portability with BISON’s newest power generator, the BS3000, the top of our reputable Chinese gasoline generator manufacturing line. Tailored for the dealer market, this generator offers the perfect blend of convenience, efficiency and high performance.
This single-cylinder portable power generator has a painted frame, giving it overall protection and making it easy to move and store. The compact structure saves a lot of space. The whole body is waterproof and dustproof, and is easy to disassemble. It has a wide option on the control panel, making it easy to operate.
The engine has an overhead valve design. The operation temperature is low, extending the serve time and making it reliable and durable. It can also save oil. Cast iron casing does not only effectively improve lubrication, but also makes engine more wear-resistant and prolongs engine life. It is with the overload protection AVR system, and oil alarm system, which effectively prevent the engine from working at low level and give more protection to it.
Incorporate our portable generator into your product lineup and provide your customers with the convenience and reliability they need. With unrivaled portability and amazing power output, this generator is sure to change the market landscape. Don’t miss the opportunity to increase your sales with this innovative portable generator.
Applications:
- In case of natural disasters, such as heavy rain and floods, when large generator cannot be transported, portable power generator is the best choice to ensure power supply for communication equipment in the disaster area.
- When the power supply is unstable or power is cut off, the small access computer room or station can use the BS3000 generator as the backup power.
- In rush repair, if the emergency repair personnel are required to carry the backup power, the power generator set can be used.
A class core parts
100% all-copper motor
Offering durability and superior energy efficiency
Domestic top carburetor
high atomization level, ensuring optimal fuel efficiency and smooth engine operation.
Powerful pull plate
Easy to start pull plate, guarantee more than 10,000 pulls
robust frames
Professional welding and painting process to ensure the beauty and stability of the rack
tight quality contorl
single-cylinder portable power generator assembly process
- Use special equipment to assemble, ensure the beaning, oil seal, governor gear effectively fit
- When assembling nuts for each muffler, spring pads need to be installed to ensure the fit of each component and the maximum noise reduction effect
- Use a special air gun, and use different torque standards for different parts
- Water test is required in each engine assembly to ensure the tightness of itself
- Pay attention to small details, add thread glue and spring washers to the bolts; add support feet to the motor bracket
- More than 20 debugging processes throughout the whole process to ensure that the machine 100% meets the factory requirements
single-cylinder portable power generator inspection process
Inspection process leaves no room for compromise, ensuring that every gasoline generator we produce is flawless.
- Water Test: Ensures 100% cylinder tightness, detecting any possible leaks.
- Unit Comprehensive Intelligent Test Cabinet: Each generator undergoes a full inspection to confirm reliability and accuracy.
- Withstand Voltage Tester Inspection: Every generator is fully inspected, ensuring precise electrical safety measurements.
- Strengthened Laboratory Standards: Our lab exceeds national sampling standards, resulting in superior product durability.
Professional technicians with 15-20 years of experience
Performance Commissioning
Machine Assembly
Artwork QA
Full Inspection
Generator Specialized Inspection
Parts assembly
Core Assembly
Power Specialized Inspection
Warranty Information
Discounted Accessories
24-hour online, 5-minute response
Engineer on-site service
Packaging & Delivery
Packaging Details: brown strong carton, generator is protected with poly bag, wooden, 1pc / carton. Lead Time: Shipped in 25 days after payment.
