HOME / GENERATOR / GASOLINE GENERATOR /
gasoline generator max 3200w rated 2800w
| no brand | 30 sets |
| OEM standard | 50 sets |
| OEM special | 100 sets |
BS3500 Specifications
| Model | BS3500 |
|---|---|
| Maximum Power of the Generator (KW) | 3200 W |
| Rated Power of the Generator (KW) | 2800W |
| Rated output voltage (Volt) | 1 Phase / 3 Phases (Optional) |
| Over Load Protector (OLP) | YES |
| Rated frequency (Hz) | 50 / 60 Hz |
| Rated Current (Amp) | 16 |
| Power factor | 1.0 (Single Phase) / 0.8 (Three Phases) |
| Fuel Tank Capacity | 15L |
| Fuel option | #92, #95 Unleaded Gasoline |
| Socket rating | 16A |
| Self start motor | Recoil start/Electric start |
| Fuel consumption at 100% Load | 1.2kg/h |
| Fuel consumption at 75% Load | 1.1kg/h |
| Fuel consumption at 50% Load | 0.85kg/h |
| Continuous Duration of operation at Rated load (hour) | 8 |
| Ignition system | T.C.I |
| Noise Level (dB) at rated load (from 4-meter distance) | 93.2 |
| Engine & Emission Specifications | |
|---|---|
| Engine Model | BS170F |
| Fuel Type | Gasoline |
| Engine Speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| Bore × Stroke | 70*54mm |
| Engine Displacement | 210 cc |
| Engine/Motor Type | 1-Cylinder, Air-Cooled, 4-Stroke, Direct Injected，OHV |
| Engine Oil grade | #5W-40 |
| Fuel Capacity | 0.6L |
| Low Oil Shutdown/Alert | Yes |
| Recoil Start | Yes |
| Electric Start | Optional |
| Alternator | |
|---|---|
| Type of alternator | 100% Copper (Corrective Wave) |
| Rotor RPM | 3000 |
| Alternator Size | 160*120mm |
products description
Are you looking for a high-quality gasoline generator that delivers reliability, performance, and customer satisfaction? BS3500 gasoline generator is the epitome of excellence in power generation.
The generator has a 50/60Hz rated frequency and can adapt to power grids in different regions. 3000 rpm speed, stable operation and low noise. Every design is designed to provide your customers with longer-lasting performance.
Wide range of uses of gasoline generator max 3200w rated 2800w:
- Provide emergency backup power: In the event of a power outage or emergency, the BS3500 can provide backup power to ensure the continued operation of critical equipment and household appliances. Its maximum power output is sufficient to support the basic electrical needs of a home or small commercial establishment.
- Outdoor activities and camping: A generator is an essential piece of equipment for outdoor enthusiasts and campers. The rated power output of the 3200w gasoline generator is 2800 watts, which is enough to drive camping lamps, electric blankets, small refrigerators and other equipment.
- Work sites and construction sites: On construction sites and construction sites, power tools and equipment are used. The high power output of the gasoline generator ensures the normal operation of various power tools.
- Power supply in rural areas: In rural areas without stable power grid, generator max 3200w rated 2800w can be used as the main or backup power supply to provide basic power services to rural residents.
A class core parts
100% all-copper motor
Offering durability and superior energy efficiency
Domestic top carburetor
high atomization level, ensuring optimal fuel efficiency and smooth engine operation.
Powerful pull plate
Easy to start pull plate, guarantee more than 10,000 pulls
robust frames
Professional welding and painting process to ensure the beauty and stability of the rack
tight quality contorl
gasoline generator max 3200w rated 2800w assembly process
- Use special equipment to assemble, ensure the beaning, oil seal, governor gear effectively fit
- When assembling nuts for each muffler, spring pads need to be installed to ensure the fit of each component and the maximum noise reduction effect
- Use a special air gun, and use different torque standards for different parts
- Water test is required in each engine assembly to ensure the tightness of itself
- Pay attention to small details, add thread glue and spring washers to the bolts; add support feet to the motor bracket
- More than 20 debugging processes throughout the whole process to ensure that the machine 100% meets the factory requirements
gasoline generator max 3200w rated 2800w inspection process
Inspection process leaves no room for compromise, ensuring that every gasoline generator we produce is flawless.
- Water test: Ensures 100% cylinder tightness, detecting any possible leaks.
- Unit comprehensive intelligent test cabinet: Each generator undergoes a full inspection to confirm reliability and accuracy.
- Withstand voltage tester inspection: Every generator is fully inspected, ensuring precise electrical safety measurements.
- Strengthened laboratory standards: Our lab exceeds national sampling standards, resulting in superior product durability.
Professional technicians with 15-20 years of experience
Performance Commissioning
Machine Assembly
Artwork QA
Full Inspection
Generator Specialized Inspection
Parts assembly
Core Assembly
Power Specialized Inspection
Customer confidence
BISON's proven reputation for quality ensures your customers get a gasoline generator they can trust, with our wide range of products minimizing returns and increasing satisfaction. With its competitive price point and high demand, the BS3500 will provide your business with huge profit potential.
Warranty Information
Discounted Accessories
24-hour online, 5-minute response
Engineer on-site service
Packaging & Delivery
Packaging details: brown strong carton, generator is protected with poly bag, wooden, 1pc / carton. Lead Time: Shipped in 25 days after payment.
